Extract 'Moments' with 4K Photo
Save those precious times in breathtaking beauty with 4K video, then capture special moments with 4K Photo. This hybrid 4K camera will keep them splendid forever.
4K Video and 4K Photo — Capture the Perfect Moment
The DMC-G7's 4K video recording capabilities allow users to capture stunningly-smooth, high-resolution scenes at an unprecedented speed of 30 fps with 8 Mpx equivalent resolution. Additionally, users can take fleeting photo opportunities within their 4K videos by using three new features - 4K Burst Shooting, 4K Burst S/S (Start/Stop) and 4K Pre-burst. All of these functions enable the user to simply select photos from the 4K video by cropping the desired frame out of the 4K burst file.
Focus on the Moment
Be ready to grab the next sudden shutter opportunity. Adding Depth From Defocus (DFD) Auto Focus (AF) technology*1 to Contrast AF has achieved both higher precision and greater speed at approximately 0.07 seconds*2. This combines with approximately 200% AF Tracking performance*3, 8 frames per second burst shooting in full resolution, and UHS-II SDXC Memory Card compatibility, to turn those once-in-a-lifetime moments into memories that last forever. *1 Contrast AF with DFD technology works only with Panasonic Micro Four Thirds lenses. *2 In AFS, with the H-FS14140. *3 Panasonic comparison with LUMIX G6.
Everything in the Right Place
Not only does the LUMIX G7 feature a stylish, sophisticated body and a snug, hand-fitting grip, it also provides an intuitive level of operation. The Live View Finder (LVF) helps you to frame your images even under bright sunlight conditions, and the body design allows you to freely customize settings. The front/rear dials control the main aperture and shutter speed settings, while easily switching to handle temporary WB and ISO adjustments. Settings can also be assigned to six function buttons.* In addition, the 4K Photo mode can quickly be active by using the 4K Photo feature on the drive mode dial. * Six buttons on the body and five buttons on the menu.
4K Video – More Details than Full HD
Whether you are watching movies or editing videos, 4K delivers a far more intense viewing experience than you have seen before. Its native resolution of 3,840 x 2,160 pixels is four times larger than Full HD, resulting in a much higher level of detail. Even if you export your footage filmed in 4K to a Full HD TV, the video files will have even better definition and crisper details than those filmed in Full HD. Note: When recording videos in 4K, use a card rated as UHS Speed Class 3.
4K Photo – Capture the Perfect Moment
Using the high resolution of 4K, Panasonic LUMIX G7 camera introduces the new 4K Photo function which allows you to extract individual frames from a video sequence (filmed at 30 frames per second) to capture those magical moments that only occur at a split second. With 4K Photo you can always be assured that you have the freedom to decide on your very own 'perfect moment'.
4K Photo Modes – Free Your Creativity
The 4K Photo function can be used in three different modes, all allowing you to capture that perfect moment at a high burst rate of 30 frames per second. 4K Burst This function is similar to photo burst shooting mode where the camera keeps shooting 8 Mpx images at ultra high burst rate, as long as the shutter button is pressed. 4K Burst S/S (Start/Stop) This standard 4K Photo function allows you to record a 4K movie so you can extract any frame as an 8 Mpx image later, so relax and wait for the moment to come. 4K Pre-Burst The '4K Pre-Burst' mode starts recording a 4K video sequence even one second before/after you press the shutter button. This allows you to capture an unpredictable moment which can happen much faster than you are able to react, giving you an extra 60 images to choose from.
Post Focus - Select the in-focus area even after shooting
Have you ever imagined that you can set sharp focus on the target subject after you shot the images? Now you can easily do it with the Post Focus function. The function has been developed based on Panasonic's 4K and high-speed, high-precision DFD (Depth From Defocus) auto focus technology. Shoot the image on the spot and save it as you like later - it's a whole new photographic experience for creative freedom. Learn more>>
High Speed Auto-Focusing with DFD Technology
Capture even the fastest moving action thanks to Panasonic's Depth From Defocus (DFD) Auto Focus (AF) technology*1. The LUMIX G7 features this brand new technology that instantly calculates the distance between the items inside the frame and drives the focus of the lens in one fast, continuous movement. This new system results in AF speeds up to 0.07 seconds*2 and a burst shooting speed with AFC of 6 frames per second. It also increases the stability of continuous focusing when shooting video. *1 Contrast AF with DFD technology works only with Panasonic Micro Four Thirds lenses. *2 In AFS, with the H-FS14140 lens.
Fast and Precise AF Tracking
The camera's Pinpoint AF gives users the capabilities to magnify their target area to set an accurate and extremely precise focus. The DMC-G7's calculated algorithm of AF Tracking ensures that the colour, size and motion vector of each subject are recognized and captured even more accurately than ever before.
Focusing in Low Light Conditions — Star Light AF
The Low Light AF feature makes it possible for users to achieve a clear focus on their subject as precisely and quickly as possible, even in extremely low-lit situations. Furthermore, the DMC-G7's newly integrated Starlight AF allows users to achieve a clear photo of a star in the night sky with auto focus. This can be achieved by an accurate calculation of the contrast value in each split AF zone.
High Image Quality Even in Low Light Conditions
The 16 megapixel Digital Live MOS Sensor in combination with the Venus Engine provides both high quality image capture and high speed signal processing. The superior noise reduction system enables crisp images even in low light conditions up to ISO 25,600. The Venus Engine vividly improves colour reproduction with an accurate evaluation of each colour – in both saturation and luminosity – allowing the camera to capture exceptionally fast-moving subjects in complete focus.
Perfect Sight and Framing
The DMC-G7's display area has been redesigned to include a high-precision OLED (Organic Light-Emitting Diode) that increases the resolution of the display area to 2,360K-dot, with approx. 1.4x / 0.7x (35 mm camera equiv.) magnification and 100% field of view. The redesigned eyecup improves switching the image output between the LVF and rear monitor automatically with a built-in sensor on the LVF. The addition of OLED enables the display area to respond at high-speed with minimum lag time, all the while enhancing resolution. Also, the OLED for the LVF boasts 10,000:1 contrast allowing for superior colour reproduction.
Focus Peaking
To give the most precise focus control possible, the LUMIX G7 has a manual focus peaking function, that shows you which area is in focus and how far the depth of field extends.
Silent Mode
This mode switches the shutter from mechanical to electronic and turns all sounds off, while suppressing emission of the AF system. Silent shooting with LUMIX G opens areas of photography that are out of reach for other photographers.
Unwire Your Creativity via Wi-Fi®
Remote Shooting / Viewing With the "Panasonic Image App", you can utilize a smartphone or tablet as controller to view the image, set the focus, release the shutter from a distance or review photographs on the large screen of your tablet. Easy Sharing You can instantly upload and share your pictures on social media using the Panasonic Image App on a smartphone or tablet. Sharing shots when browsing on the camera is also quicker thanks to a new direct uploading capability. Geotagging Location information can be tagged to the image by utilizing the GPS log of a smartphone / tablet.
Flexible Usage with Expandable Options
To offer more flexible usage, the LUMIX G7 can be combined with the DMW-FL580L External Flash, the DMW-MS2 Stereo/Shotgun Microphone and many other accessories. The LUMIX G7 is also compatible with the latest high performance BUS Class UHS-I/UHS-II SDXC/SDHC memory cards which are capable of storing all of your high-resolution 4K videos, 4K Photos and burst shooting pictures in RAW files.
Type | |
---|---|
Type | Digital Single Lens Mirrorless camera |
Recording media | SD Memory Card, SDHC Memory Card, SDXC Memory Card (Compatible with UHS-I / UHS-II UHS Speed Class 3 standard SDHC / SDXC Memory Cards) |
Image sensor size | 17.3 x 13.0 mm (in 4:3 aspect ratio) |
Lens mount | Micro Four Thirds mount |
Image Sensor | |
Type | Live MOS Sensor |
Camera effective pixels | 16.00 Mpx |
Colour filter | Primary colour filter |
Dust reduction system | Supersonic wave filter |
RECORDING SYSTEM | |
Recording file format - Still image | JPEG (DCF, Exif 2.3), RAW, MPO (with optional 3D lens) |
Recording file format - Motion picture | AVCHD (Audio format: Dolby Digital 2ch), MP4 (Audio format AAC 2ch) |
Aspect ratio | 4:3, 3:2, 16:9, 1:1 |
Image quality | RAW, RAW+Fine, RAW+Standard, Fine, StandardMPO+Fine / MPO+Standard (with optional 3D lens) |
Colour Space | sRGB, AdobeRGB |
File size (Pixels) - Still Image | [4:3] 4592 x 3448 (L) / 323 2 x2424 (M) / 2272 x 1704 (S) / 1824 x 1368 (with optional 3D lens)[3:2] 4592 x 3064 (L) / 3232 x 2160 (M) / 2272 x 1520 (S) / 1824 x 1216 (with optional 3D lens)[16:9] 4592 x 2584 (L) / 3840 x 2160 (M) / 1920 x 1080 (S) / 1824 x 1024 (with optional 3D lens)[1:1] 3424 x 3424 (L) / 2416 x 2416 (M) / 1712 x 1712 (S) / 1712 x 1712 (with optional 3D lens) |
Motion picture* - MP4*:NTSC area | [4K] 3840 x 2160: 4K/30p 100Mbps, 4K/24p 100Mbps[Full HD] 1920 x 1080: FHD/60p 28Mbps, FHD/30p: 20Mbps[HD] 1280 x 720: HD/30p 10Mbps[VGA] 640 x 480: VGA/30p 4Mbps |
Motion picture* - AVCHD*:NTSC area | [Full HD] 1920 x 1080: FHD/60p 28Mbps, 60p recording[Full HD] 1920 x 1080: FHD/60i 17Mbps, 60i recording[Full HD] 1920 x 1080: FHD/30p 24Mbps, 60i recording (sensor output is 30fps)[Full HD] 1920 x 1080: FHD/24p 24Mbps |
Continuous recordable time (Motion picture) | AVCHD [FHD/60i]: Approx. 130 min (rear monitor), 140 min (LVF) with H-FS1442AAVCHD [FHD/60i]: Approx. 130 min (rear monitor), 130 min (LVF) with H-FS14140AVCHD [FHD/60i]: Approx. 130 min (rear monitor), 140 min (LVF) with H-FS45150MP4 [4K/30p]: Approx. 100 min (rear monitor), 100 min (LVF) with H-FS1442AMP4 [4K/30p]: Approx. 100 min (rear monitor), 100 min (LVF) with H-FS14140MP4 [4K/30p]: Approx. 100 min (rear monitor), 110 min (LVF) with H-FS45150 |
Actual recordable time (Motion picture) | AVCHD [FHD/60i]: Approx. 65 min (rear monitor), 70 min (LVF) with H-FS1442AAVCHD [FHD/60i]: Approx. 65 min (rear monitor), 65 min (LVF) with H-FS14140AVCHD [FHD/60i]: Approx. 65 min (rear monitor), 70 min (LVF) with H-FS45150MP4 [4K/30p]: Approx. 50 min (rear monitor), 50 min (LVF) with H-FS1442AMP4 [4K/30p]: Approx. 50 min (rear monitor), 50 min (LVF) with H-FS14140MP4 [4K/30p]: Approx. 50 min (rear monitor), 55 min (LVF) with H-FS45150 |
Wi-Fi FUNCTION | |
Wi-Fi | IEEE 802.11b/g/n, 2412 MHz - 2462 MHz (1-11 ch), Wi-Fi / WPA / WPA2, Infrastructure mode |
NFC | No |
QR Code Connection | Yes |
Password-less connection | Yes (ON / OFF selectable) |
Viewfinder | |
Type | OLED Live View Finder (2,360K-Dots) |
Field of view | Approx. 100% |
Magnification | Approx. 1.4x / 0.7x (35 mm camera equivalent) with 50 mm lens at infinity; -1.0 m-1 |
Eye point | Approx. 17.5 mm from eyepiece lens |
Diopter adjustment | -4.0 - +4.0 (dpt) |
Eye sensor | Yes |
Eye sensor adjustment | High / Low |
Focus | |
Type | Contrast AF system |
DFD technology | Yes |
Focus mode | AFS (Single) / AFF (Flexible) / AFC (Continuous) / MF |
AF mode | Face/Eye Detection / Tracking / 49-Area / Custom Multi / 1-Area / Pinpoint (Full area touch is available) |
AF detective range | EV -4 - 18 (ISO100 equivalent) |
Starlight AF | Yes |
AF assist lamp | Yes |
AF lock | Yes (AF/AE LOCK button) |
Others | One Shot AF, Shutter AF, Half Press Release, Quick AF, Continuous AF (during motion picture recording), Eye Sensor AF, AF+MF, MF Assist, Touch MF Assist, Focus Peaking, Touch AF/AE Function, Touch Pad AF, Touch Shutter |
Exposure Control | |
Light metering system | 1728-zone multi-pattern sensing system |
Light metering mode | Multiple / Center Weighted / Spot |
Metering range | EV 0 - 18 (F2.0 lens, ISO 100 equivalent) |
Exposure mode | Program AE, Aperture Priority AE, Shutter Priority AE, Manual, |
ISO sensitivity (Standard Output Sensitivity) | Auto / Intelligent ISO / 100 (Extended) / 200 / 400 / 800 / 1600 / 3200 / 6400 / 12800 / 25600 (Changeable to 1/3 EV step)(Up to ISO6400 in motion picture recording) (ISO Auto in M mode) |
Exposure compensation | 1/3 EV step ±5EV (±3EV for motion picture) |
AE lock | Yes (AF/AE LOCK button) |
AE bracket | 3, 5, 7 frames in 1/3, 2/3 or 1 EV Step, Max. ±3 EV, single/burst |
White Balance | |
White balance | Auto / Daylight / Cloudy / Shade / incandescent / Flash / White Set 1, 2, 3, 4 / Colour temperature setting |
White balance adjustment | Blue/Amber bias, Magenta/Green bias |
Colour temperature setting | 2500-10000K in 100K |
White balance bracket | 3 exposures in blue/amber axis or in magenta/green axis |
Shutter | |
Type | Focal-plane shutter |
Shutter speed | Still image: Bulb (Max. 2 minutes), 1/4,000 - 60 secMotion picture: 1/16,000 - 1/25 secElectronic shutter: 1/16,000 - 1 sec |
Self timer | 10sec, 3 images / 2sec / 10sec |
Remote control | Remote control with Bulb function by DMW-RSL1 (Optional) |
SCENE GUIDE | |
Still image | Clear Portrait / Silky Skin / Backlit Softness / Clear in Backlight / Relaxing Tone / Sweet Child's Face / Distinct Scenery / Bright Blue Sky / Romantic Sunset Glow / Vivid Sunset Glow / Glistening Water / Clear Nightscape / Cool Night Sky / Warm Glowing Nightscape / Artistic Nightscape / Glittering Illuminations / Handheld Night Shot / Clear Night Portrait / Soft Image of a Flower / Appetizing Food / Cute Dessert / Freeze Animal Motion / Clear Sports Shot / Monochrome |
Motion picture | Clear Portrait / Silky Skin / Backlit Softness / Clear in Backlight / Relaxing Tone / Sweet Child's Face / Distinct Scenery / Bright Blue Sky / Romantic Sunset Glow / Vivid Sunset Glow / Clear Nightscape / Cool Night Sky / Warm Glowing Nightscape / Artistic Nightscape / Handheld Night Shot / Clear Night Portrait / Appetizing Food / Cute Dessert / Freeze Animal Motion / Clear Sports Shot / Monochrome |
PANORAMA SHOT | |
Panorama shot | Yes (Standard / Wide) |
BURST SHOOTING | |
Burst speed | Mechanical shutter: H: 8 frames/sec (with AFS), 6 frames/sec (with AFC), M: 6 frames/sec (with Live View), L: 2 frames/sec (with Live View)Electronic shutter: SH: 40 frames/sec, H: 10 frames/sec, M: 6 frames/sec (with Live View), L: 2 frames/sec (with Live View) |
Number of recordable images | More than 13 images (when there are RAW files with the particular speed)More than 100 images (when there are no RAW files)(depending on memory card type, aspect, picture size and compression) |
4K PHOTO MODE | |
4K Photo mode*1 | 4K Pre-Burst: 30 frames/sec, approx. 2 seconds4K Burst: 30 frames/sec, max. 29 minutes 59 seconds4K Burst (S/S): 30 frames/sec, max. 29 minutes 59 seconds(depending on memory card size and battery power) |
Exif information | Yes |
Selectable aspect ratio | Yes (4:3 / 3:2 / 16:9 / 1:1 are selectable) |
Exposure mode | Program AE/ Aperture-Priority / Sutter-Priority / Manual Exposure |
Marking function | Yes (in 4K Burst (S/S) mode) |
TIME LAPSE SHOT | |
TIME LAPSE SHOT | Yes |
STOP MOTION ANIMATION | |
STOP MOTION ANIMATION | Yes |
Flash | |
Built in flash type | TTL Built-in Flash, GN9.3 equivalent (ISO200 ・m) / GN6.6 equivalent (ISO100 ・m), Built-in Pop-up (Reference) |
Flash Mode | Auto*, Auto/Red-eye Reduction*, Forced On, Forced On/Red-eye Reduction, Slow Sync., Slow Sync./Red-eye Reduction, Forced Off * For iA, iA+ only. |
Synchronization speed | Less than 1/160 second |
Flash output adjustment | 1/3EV step ±3EV |
Flash synchronization | 1st. Curtain Sync, 2nd Curtain Sync. |
Synchronization for flash dimming and exposure compensation | Yes |
SILENT MODE | |
SILENT MODE | Yes |
Rear monitor | |
Type | TFT LCD monitor with static touch control |
Monitor size | Free-angle 3.0-inch / 3:2 aspect / Wide viewing angle |
Pixels | Approx. 1,040K-Dots |
Filed of view | Approx. 100% |
Monitor adjustment | Brightness, Contrast, Saturation, Red-Green, Blue-Yellow |
LIVE VIEW | |
Digital zoom | 2x, 4x |
Extra Tele Conversion | Still image: Max. 2xMotion picture: 2.4x (FHD), 3.6x (HD), 4.8x (VGA) |
Other functions | Level Gauge, Real-time Histogram, Guide Lines (3 patterns), Center Marker, Highlight display (Still image / motion picture), Zebra pattern (Still image / motion picture) |
DIRECTION DETECTION FUNCTION | |
Direction Detection Function | Yes |
FUNCTION BUTTON | |
Fn1, Fn2, Fn3, Fn4, Fn5, Fn6, Fn7, Fn8, Fn9, Fn10, Fn11 | Exposure Comp. / Wi-Fi / Q.MENU / LVF/Monitor Switch / AF/AE LOCK / AF-ON / Preview / One Push AE / Touch AE / Level Gauge / Focus Area Set / Zoom Control / Cursor Button Lock / Dial Operation Switch / Photo Style / Filter Select / Aspect Ratio / Picture Size / Quality / AFS/AFF / Metering Mode / Burst Rate / 4K PHOTO / Auto Bracket / Self Timer / Highlight Shadow / i. Dynamic / i. Resolution / HDR / Electronic Shutter / Flash Mode / Flash Adjust. / Ex. Tele Conv. / Digital Zoom / Stabilizer / Snap Movie / Motion Pic. Set / Picture Mode / Mic. Directivity Adjust / Silent Mode / Peaking / Histogram / Guide Line / Zebra Pattern / Monochrome Live View / Rec Area / Step Zoom / Zoom Speed / Touch Screen / Sensitivity / White Balance / AF Mode/MF / Restore to Default |
PHOTO STYLE | |
Still image and motion picture | Standard / Vivid / Natural / Monochrome / Scenery / Portrait / Custom / Cinelike D* / Cinelike V* *When Creative Video Mode is selected. |
CREATIVE CONTROL | |
Still image | Expressive / Retro / Old Days / High Key / Low Key / Sepia / Monochrome / Dynamic Monochrome / Rough Monochrome / Silky Monochrome / Impressive Art / High Dynamic / Cross Process / Toy Effect / Toy Pop / Bleach Bypass / Miniature Effect / Soft Focus / Fantasy / Star Filter / One Point Colour / Sunshine |
Motion picture | Expressive / Retro / Old Days / High Key / Low Key / Sepia / Monochrome / Dynamic Monochrome / Impressive Art / High Dynamic / Cross Process / Toy Effect / Toy Pop / Bleach Bypass / Miniature Effect / Fantasy / One Point Colour |
CREATIVE VIDEO MODE | |
Exposure mode | Program AE / Aperture-Priority / Sutter-Priority / Manual Exposure |
MOTION PICTURE FUNCTION | |
Cinelike gamma | Cinelike D / Cinelike V |
Flicker reduction | [1/50] / [1/60] / [1/100] / [1/120] / OFF |
Playback | |
Playback function | 30-thumbnail display, 12-thumbnail display, Calendar display, Zoomed playback (Max. 16x), Slideshow (All / Picture Only / Video Only / 4K PHOTO / 3D / Category Selection / Favorite, duration & effect is selectable), Playback Mode (Normal / Picture / Video / 4K PHOTO / 3D Play / Category / Favorite), Location Logging, RAW Processing, Clear Retouch, Title Edit, Text Stamp, Video Divide, Time Lapse Video, Stop Motion Video, Resize, Cropping, Rotate, Rotation Display, Favorite, DPOF Print Set, Protect, Face Recognition Edit, Picture Sort, Creating Still Pictures from a Motion Picture |
IMAGE PROTECTION / ERASE | |
Protection | Single / Multi |
Erase | Single / Multi / All / Except Favorite |
Direct Print | PictBridge compatible |
Interface | |
USB | USB 2.0 High Speed Multi |
HDMI | microHDMI TypeD / VIERA LinkVideo: Auto / 4K / 1080p / 1080i / 720p / 480pAudio: Stereo |
Audio video output | Monaural Type, NTSC* Check the website of the Panasonic sales company in your country or region for details on the products that are available in your market. |
Remote input | φ2.5 mm for remote |
External microphone input | φ3.5 mm for external microphoneStereo/Lens Auto/Shotgun/Super Shotgun/Manual is selectable when attaching DMW-MS2 (optional). |
Microphone | Stereo, Wind-cut: OFF / Low / Standard / High / AUTO |
Speaker | Monaural |
LANGUAGE | |
OSD language | Japanese, English, German, French, Italian, Spanish, Portuguese, Chinese (Traditional) |
General | |
POWER - Battery | Li-ion Battery Pack (7.2V, 1200mAh, 8.7Wh) (Included)Battery Charger |
POWER - Battery life (CIPA standard) | Approx. 360 images with H-FS1442AApprox. 350 images with H-FS14140Approx. 350 images with H-FS45150 |
DIMENSIONS & WEIGHT - Dimensions (W x H x D) | 124.9 x 86.2 x 77.4 mm / 4.92 x 3.39 x 3.05 inch (excluding protrusions) |
DIMENSIONS & WEIGHT - Weight | Approx. 410 g / 0.90 lb (SD card, Battery, Body)Approx. 360 g / 0.79 lb (Body only)Approx. 520 g / 1.15 lb (SD card, Battery, H-FS1442A lens included)Approx. 675 g / 1.49 lb (SD card, Battery, H-FS14140 lens included)Approx. 610 g / 1.34 lb (SD card, Battery, H-FS45150 lens included)Approx. 720 g / 1.59 lb (SD card, Battery, H-FS1442A + H-FS45150 lenses included) |
OPERATING ENVIRONMENT - Operating temperature | 0°C to 40°C (32°F to 104°F) |
OPERATING ENVIRONMENT - Operating humidity | 10%RH to 80%RH |
STANDARD ACCESSORIES - Software | PHOTOfunSTUDIO 9.7 PE(Windows Vista / Windows 7 / Windows 8 / Windows 8.1)SILKYPIX® Developer Studio 4.3 SE(Windows Vista / Windows 7 / Windows 8 / Windows 8.1, Mac OS X v10.5 - v10.10)LoiLoScope (Trial version)(Windows Vista / Windows 7 / Windows 8 / Windows 8.1) |
STANDARD ACCESSORIES - Standard accessories | DMC-G7W Kit Hot Shoe Cover, Body Cap, Battery Pack, Battery Charger, USB Connection Cable, Shoulder Strap, DVD, AC Cable*, Lens Hood, Lens Cap, Lens Rear Cap* Depends on the country or region. |
INTERCHANGEABLE LENS-1 | |
Lens Name | LUMIX G VARIO 14-42 mm / F3.5-5.6 ASPH. / MEGA O.I.S. |
Lens Construction | 12 elements in 9 groups (1 Aspherical lens) |
Mount | Micro Four Thirds mount |
Optical Image Stabilizer | Yes |
Focal Length | f=14 to 42 mm (35 mm camera equivalent: 28 to 84 mm) |
Aperture Type | 7 diaphragm blades / Circular aperture diaphragm |
Aperture | F3.5 (Wide) - F5.6 (Tele) |
Minimum Aperture | F22 |
Closest Focusing Distance | 0.3 m / 1 ft |
Maximum magnification | Approx. 0.16x / 0.32x (35 mm camera equivalent) |
Diagonal Angle of View | 75° (Wide) to 29° (Tele) |
General - Filter Size | φ52 mm / 2.05 in |
General - Max. Diameter | φ60.6 mm / 2.39 in |
General - Overall Length | Approx. 63.6 mm / 2.50 in (from the tip of the lens to the base side of the lens mount) |
General - Weight [g] | Approx. 165 g |
General - Weight [oz] | Approx. 5.82 oz |
INTERCHANGEABLE LENS-2 | |
Lens Name | LUMIX G VARIO 45-150 mm / F4.0-5.6 ASPH. / MEGA O.I.S. |
Lens Construction | 12 elements in 9 groups (2 aspherical lenses, 1 UHR lens) |
Mount | Micro Four Thirds mount |
Optical Image Stabilizer | Yes (MEGA O.I.S.) |
Focal Length | f=45 to 150 mm (35 mm camera equivalent: 90 to 300 mm) |
Aperture Type | 7 diaphragm blades / Circular aperture diaphragm |
Aperture | F4.0 (Wide) - F5.6 (Tele) |
Minimum Aperture | F22 |
Closest Focusing Distance | 0.9 m / 3.0 ft |
Maximum magnification | Approx. 0.17x / 0.35x (35 mm camera equivalent) |
Diagonal Angle of View | 27° (Wide) to 8.2° (Tele) |
General - Filter Size | φ52 mm / 2.05 in |
General - Max. Diameter | φ62 mm / 2.44 in |
General - Overall Length | Approx. 73 mm / 2.9 in (from the tip of the lens to the base side of the lens mount) |
General - Weight [g] | Approx. 200 g |
General - Weight [oz] | Approx. 7.1 oz |
