Versatile 4K 60p Performance
The industry's smallest and lightest* 4K 60p camcorder in a mobile compact body packs a remarkable optical performance and pro functions into this active handheld with no compromise in quality.
Industry's Smallest and Lightest 4K 60p Camcorder
While excelling in mobility and portability, the compact body considers the weight balance of the advanced functions when shooting.
Wide 25mm* and Optical 24x Zoom Lens
The lens covers the range from 25mm wide-angle to 600mm tele with a 24x zoom. i.ZOOM achieves 32x zoom with 4K resolution, and 48x zoom with FHD.* 35mm camera equivalent.
4K High-Precision AF
Face Detection precisely captures subjects on-site free from out of focus problems and insufficient exposure. Also, by adding color recognition, tracking subjects is improved, without interruption, when the face moves to either side.
HYBRID O.I.S.
In both UHD/FHD modes, in addition to Optical Image Stabilization, Electronic Image Stabilization detects and corrects handshake in the 5-axis direction. The Ball O.I.S. System reduces friction in the drive section, especiallyimproving the correction of small-amplitude blurring.
Heat-Dispersing Design
A new ultrathin fan disperses heat in a camcorder with integrated lens and 4K 60p recording. It is the industry's smallest and lightest unit with low power consumption.
Versatile Recording Modes
Supports a high bit rate of 200 Mbps for 59.94p/50p video recording with HEVC (LongGOP/10 bit 4:2:0/MOV) codec, and 120/100fps* Super Slow-motion with 10-bit recording in FHD.* 59.94Hz: 120fps, 50Hz: 100fps
4:2:2 10-bit Internal Recording
Records a 4:2:2 10-bit color profile of up to LongGOP UHD 29.97p/25p (150 Mbps), or FHD 59.94p/50p (100 Mbps) with SD cards. Outputs 10-bit UHD 59.94p/50p images via HDMI.
Multi-Formats Supported
Versatile formats and bit rates are available. In addition to easy-to-edit MOV and MP4, 720p AVCHD 8-Mbps (PM) mode is included.
Full-HD Live Streaming
RTSP/RTP/RTMP/RTMPS-compatible HD streaming enables direct connection and distribution of relays for concerts, sports events, and news flashes to Facebook, YouTube, etc.* The handle unit and mic are optional.
Wireless Control from a Tablet or Smartphone
A Wi-Fi module is built-in, so Wi-Fi connection of only the body is possible. Using a tablet or smartphone app HC ROP, wireless camera settings, and lens control are also possible.
| SENSOR SECTION | |
|---|---|
| Image Sensor | 1/2.5-type (inch) MOS Sensor |
| Effective Pixles | 8.29 megapixels |
| LENS SECTION | |
| F Value | F1.8 ― 4.0 |
| Optical Zoom | 24x |
| Focal Length | 4.12 ― 98.9mm |
| 35 mm Film Camera Equivalent | 25.0 ― 600.0 mm |
| Filter Diameter | 62 mm |
| Lens Brand | Leica Dicomar Lens |
| CAMERA SECTION | |
| Minimum Illumination | 1.5 lx (F1.8, Super Gain +, 1/30) |
| Focus | Auto / Manual |
| Zoom - Intelligent OFF | 24x |
| Zoom - Intelligent ON | Max. 48x (UHD 32x) |
| Zoom - Digital | 2x / 5x / 10x |
| Shutter Speed - 59.94 Hz mode | 59.94i/59.94p: 1/60, 1/100, 1/120, 1/180, 1/250, 1/350, 1/500, 1/750, 1/1000, 1/1500,1/2000, 1/3000, 1/4000, 1/8000 sec29.97p: 1/30, 1/50, 1/60, 1/100, 1/120, 1/180, 1/250, 1/350, 1/500, 1/750, 1/1000, 1/1500,1/2000, 1/3000, 1/4000, 1/8000 sec23.98p: 1/24, 1/48, 1/50, 1/60, 1/100, 1/120, 1/180, 1/250, 1/350, 1/500, 1/750, 1/1000, 1/1500, 1/2000, 1/3000, 1/4000, 1/8000 sec |
| Shutter Speed - 50.00 Hz mode | 50i/50p: 1/50, 1/60, 1/100, 1/125, 1/180, 1/250, 1/350, 1/500, 1/750, 1/1000, 1/1500, 1/2000, 1/3000, 1/4000, 1/8000 sec25p: 1/25, 1/50, 1/60, 1/100, 1/125, 1/180, 1/250, 1/350, 1/500, 1/750, 1/1000, 1/1500, 1/2000, 1/3000, 1/4000, 1/8000 sec |
| Slow Shutter Speed - 59.94 Hz mode | 59.94i/59.94p: 1/8, 1/15, 1/30 sec29.97p: 1/8, 1/15 sec23.98p: 1/6, 1/12 sec |
| Slow Shutter Speed - 50.00 Hz mode | 50i/50p: 1/6, 1/12, 1/25 sec25p: 1/6, 1/12 sec |
| Super Slow Recording Frame Rate - 59.94 Hz mode | FHD 120 fps (1/2 speed at 60p, 1/4 speed at 30p, 1/5 speed at 24p) |
| Super Slow Recording Frame Rate - 50.00 Hz mode | FHD 100 fps (1/2 speed at 50p, 1/4 speed at 25p) |
| ND Filter | 1/4, 1/16, 1/64, OFF |
| IR Filter | Incorporates the ON/OFF control function |
| White Balance | Auto / ATW LOCK / 3200K / 5600K / VAR (2000K—15000K) / Ach Fixed / Bch Fixed |
| Iris | Auto / Manual |
| Image Stabilizer | Ball O.I.S., 5-Axis HYBRID O.I.S. (UHD/FHD) |
| RECORDING SECTION | |
| Recording Media | SDHC/SDXC Memory Card |
| Recording Format | MOV, MP4, AVCHD |
| Video Compression Method | MOV/MP4: H.264/MPEG-4 AVC High Profile, H.265/MPEG-H HEVC Main10 ProfileAVCHD: H.264/MPEG-4 AVC High Profile |
| Audio Compression Method | MOV: LPCM (24bit 2ch)MP4: AAC (16bit 2ch)AVCHD: Dolby Audio (16bit 2ch) |
| System Frequency | 59.94Hz / 50.00Hz |
| Recording / Playback Mode - MOV (HEVC) | [4:2:0 10bit] UHD 3840x2160 59.94p/50.00p HEVC 200M: Average 200Mbps (VBR) UHD 3840x2160 29.97p/25.00p/23.98p HEVC 150M: Average 150Mbps (VBR) |
| Recording / Playback Mode - MOV | [4:2:0 8bit] UHD 3840x2160 59.94p/50.00p 150M: Average 150Mbps (VBR) UHD 3840x2160 29.97p/25.00p/23.98p 100M: Average 100Mbps (VBR)[4:2:2 10bit] UHD 3840x2160 29.97p/25.00p/23.98p 150M: Average 150Mbps (VBR) FHD 1920x1080 59.94p/50.00p 200M (ALL-Intra): Average 200Mbps (VBR) FHD 1920x1080 29.97p/25.00p/23.98p 100M (ALL-Intra): Average 100Mbps (VBR) FHD 1920x1080 59.94i/50i 100M (ALL-Intra): Average 100Mbps (VBR) FHD 1920x1080 59.94p/50.00p 100M: Average 100Mbps (VBR) FHD 1920x1080 29.97p/25.00p/23.98p/59.94i/50.00i 50M: Average 50Mbps (VBR) |
| Recording / Playback Mode - MP4 (HEVC) | [4:2:0 10bit] UHD 3840x2160 59.94p/50.00p HEVC 100M: Average 100Mbps (VBR) UHD 3840x2160 29.97p/25.00p/23.98p HEVC 72M: Average 72Mbps (VBR) |
| Recording / Playback Mode - MP4 | [4:2:0 8bit] UHD 3840x2160 29.97p/25.00p/23.98p 72M: Average 72Mbps (VBR) FHD 1920x1080 59.94p/50.00p/23.98p 50M: Average 50Mbps (VBR) |
| Recording / Playback Mode - AVCHD | [4:2:0 8bit] PS 1920x1080 59.94p/50.00p: Average 25Mbps (VBR) PH 1920x1080 59.94i/50.00i/23.98p: Average 21Mbps (VBR) HA 1920x1080 59.94i/50.00i: Average 17Mbps (VBR) PM 1280x720 59.94p/50.00p: Average 8Mbps (VBR) |
| Recording / Playback Mode - P2 | — |
| LIVE STREAMING | |
| Video Compression Format | H.264/MPEG-4 AVC Main Profile, High Profile |
| Video Resolution | 1920 x 1080 (FHD), 1280 x 720 (HD), 640 x 360, 320 x 180 |
| Streaming Method | Unicast, Multicast |
| Frame Rate | System frequency = 59.94 Hz: 30 fps, 60 fpsSystem frequency = 50.00 Hz: 25 fps, 50 fps |
| Bit Rate | 24 Mbps, 20 Mbps, 16 Mbps, 14 Mbps, 8 Mbps, 6 Mbps, 4 Mbps, 3 Mbps, 2 Mbps, 1.5 Mbps, 1 Mbps, 0.7 Mbps, 0.5 Mbps |
| Audio Compression Format | AAC-LC, 48 kHz/16 bit, 2ch |
| Network Protocol | RTSP/RTP/RTMP/RTMPS |
| STILL IMAGE SECTION | |
| Recording Format | JPEG (DCF/Exif2.2) |
| Recording Image Size* | Video Playback Mode: 3840 x 2160 (16:9), 1920 x 1080 (16:9), 1280 x 720 (16:9) |
| GENERAL SECTION | |
| Power Supply | 7.28V (Battery) / 12V (AC Adaptor) |
| Power Consumption | 14.4W (LCD Monitor) |
| Dimensions (W x H x D) | Approx. 129 x 93 x 257 mm (5.08 x 3.66 x 10.1 inch) |
| Weight | Body: approx. 0.9kg (1.98 lb) (body only, excluding handle, lens hood, battery, and accessories)Shooting: approx. 1.2kg (2.65 lb) (including lens hood, battery, and eyecup) |
| LCD Monitor | 8.88 cm (3.5-inch) Wide LCD monitor (About 2,760,000 dots) (For Europe)3.5-inch Wide LCD monitor (About 2,760,000 dots) (For North America / Asia) |
| Viewfinder | 0.61 cm (0.24-inch) Wide EVF (About 1,560,000 dots) (For Europe)0.24-inch Wide EVF (About 1,560,000 dots) (For North America / Asia) |
| Manual Ring | Focus / Zoom or Iris |
| Accessory Shoe | Yes |
| LED Video Light - Average Illumination | — |
| LED Video Light - Irradiation Angle | — |
| LED Video Light - Color Temperature | — |
| INTERFACE SECTION | |
| Video - SDI OUT | — |
| Video - HDMI | Type A x 1 (VIERA Link not supported)Output format:2160/59.94p/50.00p/29.97p/25.00p/23.98p,1080/59.94p/50.00p/29.97p/25.00p/23.98p/59.94i/50.00i,720/59.94p/50.00p, 480/59.94p, 576/50.00p |
| Audio Input - Built-in Microphone | Stereo microphone |
| Audio Input - Microphone Input | 3.5mm stereo mini jack x 1 |
| Audio Input - XLR Input | — |
| Audio Output - SDI | — |
| Audio Output - HDMI | 2 ch (LPCM 24bit) |
| Audio Output - Headphone | 3.5 mm diameter stereo mini jack x 1 |
| Audio Output - Speaker | 15 mm diameter, round x 1 |
| Other Input/Output - Camera Remote | 2.5mm super mini jack x 1 |
| Other Input/Output - USB 2.0 HOST | — |
| Other Input/Output - USB 2.0 DEVICE | Micro-AB connector, 5-pin, mass storage function (read only) |
| Other Input/Output - DC IN | DC 12V (11.4V ― 12.6V) EIAJ Type4 |
| Wi-Fi - Standard | IEEE 802.11b/g/n |
| Wi-Fi - Frequency | 2.4GHz band |
| STANDARD ACCESSORY | |
| AC Adaptor | Yes |
| AC Cable | Yes |
| Rechargeable Battery Pack | Yes (5,900mAh) |
| Handle Unit | — |
| Battery Charger | — |
| IR Remote | — |
| HDMI Cable | — |
| AV Cable | — |
| USB Cable | — |
| USB LAN Conversion Adaptor | — |
| Microphone Holder | — |
| Microphone Holder Screws | — |
| Input Terminal Cap | — |
| Eye Cup | Yes |
| Lens Hood | Yes |
| Editing Software | — |
